Introduction

In the field of piping systems engineering, waterhammer and surge transient events are complex phenomena that can have devastating consequences if not properly addressed. AFT Impulse is a practical tool designed to help engineers tackle these challenges with ease. In this article, we will delve into the features and capabilities of AFT Impulse, exploring its steady-state solver, transient flow solution engine, and advanced modeling capabilities.

Steady-State Solver

AFT Impulse incorporates an integral steady-state solver that calculates the initial conditions of a piping system. This solver uses a modified Newton-Raphson matrix iteration to determine steady-state solutions. The solver is based on the same proven technology found in AFT Fathom, ensuring accuracy and reliability. By providing a robust steady-state solver, AFT Impulse enables engineers to establish a solid foundation for their transient analysis.

Transient Flow Solution Engine

The transient flow solution engine in AFT Impulse is based on the Method of Characteristics. This method utilizes a prescribed relationship between time step and distance step, allowing for a direct solution of each time step. This approach makes AFT Impulse highly efficient, enabling engineers to quickly and accurately analyze complex transient events.

Advanced Modeling Capabilities

AFT Impulse offers a range of advanced modeling capabilities that enable engineers to simulate a wide variety of transient events. Users can specify transients on both a time and event basis, allowing for a high degree of flexibility and control. For example, engineers can initiate a pump startup based on the pressure at a selected location in the system or a valve closure upon the flow direction at a selected location.

Pump Modeling

Pump modeling is a critical aspect of piping systems engineering, and AFT Impulse provides a range of options for modeling pumps. Engineers can choose from simple fixed-flow models to sophisticated four-quadrant effects models that account for various combinations of forward and reverse flow and rotation. Additionally, start and trip modeling can be performed using specified speed vs. time or accounting for pump/driver inertia and driver torque vs. speed.

Force Calculations

From the hydraulic solution of time-varying pressure and flow, AFT Impulse can calculate transient unbalanced forces. Users can define force sets that can be either a force pair (e.g., bends at the beginning and end of a run) or a point force (e.g., at the termination of a run where a pipe run contains an untied expansion joint). Engineers can select to include forces from pressure, momentum, and frictional pressure drop reaction.

Benefits of AFT Impulse

AFT Impulse offers a range of benefits for piping systems engineers, including:

Improved accuracy: AFT Impulse's advanced modeling capabilities and transient flow solution engine enable engineers to accurately simulate complex transient events.
Increased efficiency: AFT Impulse's direct solution approach makes it highly efficient, allowing engineers to quickly and easily analyze complex piping systems.
Enhanced flexibility: AFT Impulse's advanced modeling capabilities and user-defined force sets enable engineers to simulate a wide variety of transient events.
Reduced risk: By accurately simulating complex transient events, engineers can identify potential risks and take steps to mitigate them.

Conclusion

AFT Impulse is a comprehensive tool designed to help piping systems engineers tackle complex transient events with ease. Its advanced modeling capabilities, transient flow solution engine, and user-defined force sets make it an invaluable resource for engineers working on piping systems projects. By providing a robust and efficient solution for transient analysis, AFT Impulse enables engineers to improve accuracy, increase efficiency, enhance flexibility, and reduce risk.

Case Studies

AFT Impulse has been successfully used in a range of applications, including:

Water treatment plant: AFT Impulse was used to simulate the transient behavior of a water treatment plant's piping system, enabling engineers to identify potential risks and take steps to mitigate them.
Power plant: AFT Impulse was used to analyze the transient behavior of a power plant's piping system, enabling engineers to optimize system performance and reduce the risk of damage.
Industrial process: AFT Impulse was used to simulate the transient behavior of an industrial process's piping system, enabling engineers to identify potential risks and take steps to mitigate them.
