Problem Description

When using the Move/Array transform (W) in Sketcher, the resulting sketch has many new DoF (degrees of freedom) namely both x- and y-coordinates for all new copies. This can be frustrating, especially when trying to create precise and accurate designs. To address this issue, it would be very helpful to automatically add point-coincident-constraints from the original to the copies.

Two Cases

There are two cases to consider when dealing with the Move/Array transform:

Case A: Both Start and Endpoints Belong to the Selected Set of Elements

In this case, the two or three points are used for the coincidences between parent and child. This means that the original and copied elements will share the same coordinates, ensuring that the design remains accurate and precise.

Case B: Otherwise

If the start and endpoints do not belong to the selected set of elements, the set of elements has a "first" point. This point should be used together with a blue construction geometry vector to fix the children. This approach ensures that the copied elements are properly constrained and aligned with the original element.

Full Version Info

The following information provides details about the system configuration and version:

OS: Arch Linux (KDE/plasmax11/xcb)
Architecture: x86_64
Version: 1.0.0.39109 (Git)
Build type: Release
Branch: makepkg
Hash: 2fcc5317fe3aee96ca73475986a577719fc78e20
Python: 3.13.2
Qt: 6.8.2
Coin: 4.0.3
Vtk: 9.4.1
OCC: 7.8.1
Locale: English/United States (en_US)
Stylesheet/Theme/QtStyle: unset/FreeCAD Classic/oxygen
Installed mods:
- fasteners: 0.5.24
- ThreadProfile: 1.90.0
- 3D_Printing_Tools

Subproject(s) Affected

None of the subprojects are affected by this issue.

Anything Else?

It's worth noting that this suggestion was previously the default in some former versions of FreeCAD. This suggests that the feature was removed or changed at some point, leading to the current behavior.

Side-Note

A minor issue worth mentioning is the inconsistent counting of columns and rows in the Move/Array transform. The number of columns is 0-based, counting the number of additional elements, while the number of rows is 1-based, counting the total number of rows. This can be confusing and may lead to errors.
